Price
Hours
Serial #
Engine & Performance
• Horsepower: 68.3 HP (Gross)
• Engine: Kubota V2607-CR-TE4 Turbocharged Diesel
• Rated Operating Capacity (ROC): 2,100 lbs (35% of Tipping Load) / 3,000 lbs (50% of Tipping Load)
• Tipping Load: 6,000 lbs
• Bucket Breakout Force: 4,614 lbs
• Travel Speed: Low: 4.9 mph / High: 7.1 mph
Dimensions & Weight
• Operating Weight: ~8,035 – 8,465 lbs (depending on cab/tracks)
• Height to Hinge Pin: 118.5 inches
• Overall Width: 68″ / 74″ (with bucket)
• Ground Clearance: 9.1 inches
Hydraulics & Features
• Auxiliary Hydraulics Flow: 17.4 – 27.0 GPM (GPM)
• Controls: ISO Pilot Controls
• Lift: Vertical Lift Arm Path
• Standard Features: Self-leveling function, Hydraulic Quick Coupler, Multi-function levers
Operator Comfort
• Station: Open ROPS/FOPS Cab
Key Benefits
• Vertical Lift: Excellent dumping height for loading trucks.
• Powerful: High breakout force for tough jobs.
• Comfortable: Available cab with A/C and heat.
• Versatile: Handles various attachments with standard hydraulics
